Din Rail Industrial Power Converter 60W Output Power 15V / 4A

MOQ:	1
Price:	Negotiable
Standard Packaging:	Box Packing
Delivery Period:	5-8 working days
Payment Method:	T/T,Western Union,MoneyGram
Supply Capacity:	10000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin

Guangdong, China

Brand Name

KRONZ

Certification

Model Number

PRP60-15A40

DC Input Voltage:

120~370VAC

Weight:

Output Power:

Safety Standards:

UL/ IEC62368-1, IS13252(Par1)&EN62368-1, EN61558-1/ -2-16, BS EN 62368-1

Output Voltage&Current:

15V/40.A

Input Frequency:

47~63Hz

Maximum Capacitive Load (μF):

AC Input Voltage:

85~264VAC

Highlight:

Din Rail Industrial Power Converter

Industrial Power Converter 60W

Power Converter 15V

Product Description

Din Rail Industrial Power Converter 60W Output Power 15V / 4A

Product Specifications

Attribute	Value
DC Input voltage	120~370VAC
Weight	175g
Output Power	60W
Safety standards	UL/IEC62368-1, IS13252(Par1)&EN62368-1, EN61558-1/-2-16, BS EN 62368-1
Output Voltage & Current	15V/4.0A
Input frequency	47~63Hz
Maximum capacitive load (μF)	8000
AC Input voltage	85~264VAC

Product Description

The Industrial Power Supply is a high-quality product designed to meet the power supply needs of industrial applications. This Industrial Power Converter offers a maximum capacitive load of 8000 μF, ensuring stable and reliable power delivery to your equipment.

With an output power of 60W, this AC/DC Converter provides sufficient power to drive various industrial devices and machinery. The input current required is 0.5A at 115VAC and 0.25A at 230VAC, making it versatile and suitable for different power input scenarios.

Key Features

Industrial-Grade Design - DIN-rail mounting (TS35 compatible) for easy panel integration
Wide Input Range - 85-264V AC or 120-370V DC (universal input)
Precise 15V/4A Output - Regulated DC power for sensors, PLCs, and actuators
High Efficiency (≥90%) - Reduces energy waste and heat generation
Protections - Short-circuit, overvoltage, and thermal overload safeguards
Operating Temp: -25°C to +70°C (with derating above 50°C)
Safety Certifications - CE, UL, and EN 61000-6-2/4 (EMC compliance)

Product Images

Technical Parameters

Basic Specifications

Model number for ordering: PRP60-15A40

Output power: 60W

Nominal output voltage & current: 15V/4.0A

Adjustable output voltage range (ADJ): 13.5~18.0

Efficiency (230VAC, %/Typ.): 89

Maximum capacitive load (μF): 8000

Input Characteristics

AC Input voltage: 85~264VAC

DC Input voltage: 120~370VDC

Input current: 0.5A (115VAC); 0.25A (230VAC)

Input frequency: 47~63Hz

Output Characteristics

Output voltage accuracy: ±2%

Load regulation: ±1% (230VAC)

Ripple (20MHz): Max. 120mV

Power-down hold time: 12ms (115VAC); 30ms (230VAC)

General Features

Operating temperature: -40~+70°C

Weight: 60g

Safety standards: IS13252(Par1)&EN62368-1,BS EN 62368-1(Report); In line with UL/IEC62368-1,IEC/EN61010-1,IEC/EN61558-1,IEC60335-1

Applications

KRONZ Industrial Power Supply is a versatile and reliable product designed to meet the power needs of various industrial applications. With its high-quality components and advanced technology, this AC/DC Converter is ideal for a wide range of scenarios where a stable and efficient power supply is essential.

Manufactured in Guangdong, China, this Industrial DC Power Supply carries the prestigious CE certification, ensuring compliance with international standards for safety and quality. The minimum order quantity is just 1 unit, and the price is negotiable, making it accessible for both small-scale and large-scale industrial operations.

Support and Services

Our Industrial Power Supply product comes with comprehensive technical support and services to ensure smooth operation and optimal performance. Our team of experts is available to assist with any product-related inquiries, troubleshooting, and maintenance needs.

Packing and Shipping

Product Packaging: The Industrial Power Supply is carefully packaged in a sturdy cardboard box to ensure safe transit. The product is secured with foam padding to prevent any damage during shipping.

Shipping Information: Orders are typically processed within 1-2 business days. We offer various shipping options, including standard ground shipping and expedited shipping for faster delivery. Once your order is shipped, you will receive a tracking number to monitor the status of your delivery.
