48V RJ45 Ethernet Connector Modular Plug Shielded Cat6 Connectors Customized

MOQ:	80
Price:	Negotiable
Standard Packaging:	Polybag packing
Delivery Period:	5-8 working days
Payment Method:	T/T,Western Union,MoneyGram
Supply Capacity:	100000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin

Guangdong, China

Brand Name

KRONZ

Certification

Model Number

RJ45S-5/E60K

Contact Carrier Material:

PA,black

Contact Nut Material:

Brass,nickel-plated

Seal Material:

FPM/FKM

Contact Suface Material:

Brass,gold-plated

Material Of Grip Body:

TPU,black

Voltage:

Length:

Customized

Highlight:

RJ45 Ethernet Connector Shielded

48V RJ45 Ethernet Connector

Shielded Cat6 Connectors Customized

Product Description

48V RJ45 Ethernet Connector Modular Plug Shielded Cat6 Connectors Customized

Product Specifications

Attribute	Value
Contact carrier material	PA, black
Contact nut material	Brass, nickel-plated
Seal material	FPM/FKM
Contact surface material	Brass, gold-plated
Material of grip body	TPU, black
Pin	4, 8
Voltage	48V
Length	Customized

Product Description

Our RJ45 connectors are made with durable and high-quality materials to ensure long-lasting performance. The contact surface material used is brass, which is gold-plated to prevent corrosion and oxidation, providing a stable and reliable connection. The connector is also designed to prevent dust and water from entering, making it ideal for outdoor and harsh environments.

Our RJ45 connectors are available in 24AWG and 26AWG wire gauges, providing flexibility in selecting the perfect connector for your specific networking requirements. The thread type is RJ45, which is a standard interface for Ethernet connections.

Technical Specifications

Thread type	RJ45
Contact nut material	Brass, nickel-plated
Contact surface material	Brass, gold-plated
Contact carrier material	PA, black
Housing material	TPU, black
Seal material	FPM/FKM
Insulation resistance	≥100MΩ
Contact resistance	≤5mΩ
Pollution degree	3
Ambient temperature	-25~+85℃
Mating cycles	>100
Degree of protection	IP20

Pin Assignment

Pin assignment	Wire color	PIN	Rated current	Voltage	Wire gauge	Cable outlet	Length	Model No.
	1 = WH/OR 2 = OR 3 = WH/GN 4 = BU 5 = WH/BU 6 = GN 7 = WH/BN 8 = BN	8	1.5A	48V	4×2×0.16, shielded (4×2×26AWG) Blueish green, PVC, OD=6.6	Straight	5M	RJ45S-5/E60K

Applications

One of the primary applications of this product is in the installation and maintenance of network cables. The RJ45 connector is designed to connect Ethernet cables to devices such as routers, switches, and servers. It is compatible with Cat6 RJ45 connectors, which support high-speed data transfer rates of up to 10 Gbps. This makes it ideal for use in data centers, offices, and other network-intensive environments.
