M12 Industrial Ultrasonic Sensors NPN 5 Pin Detection Range 200 - 4000mm
  • name
  • name

M12 Industrial Ultrasonic Sensors NPN 5 Pin Detection Range 200 - 4000mm

MOQ: 10 pieces
Price: Negotiable
Standard Packaging: Polybag packing
Delivery Period: 5-8 working days
Payment Method: T/T,Western Union,MoneyGram
Supply Capacity: 100000 pieces per month
Detail Information
Product Description
Detail Information
Place of Origin
Guangdong, China
Brand Name
KRONZ
Certification
CE
Model Number
U30-D4000N(P)1T-R00A
Detection Range:
200-4000mm
Blind Zone:
0-200mm
Resolution:
0.17-1.5mm
Repeatability:
±0.15%F.S.
Response Time:
162ms
Initialization Time:
＜ 500ms
Supply Voltage:
10-30V DC,reverse-polarity Protection
Load Impedance:
I/ ＜ 300 Ohm,U/ ＞ 1k Ohm
No-load Current:
≤30mA
Highlight:

M12 Industrial Ultrasonic Sensors

,

Industrial Ultrasonic Sensors 4000mm

,

Ultrasonic Sensor NPN 5 Pin

Product Description
M12 Industrial Ultrasonic Sensors NPN 5 Pin Detection Range 200 - 4000mm
Product Specifications
Attribute Value
Detection range 200-4000mm
Blind zone 0-200mm
Resolution 0.17-1.5mm
Repeatability ±0.15%F.S.
Response time 162ms
Initialization time ＜ 500ms
Supply voltage 10-30V DC, reverse-polarity protection
Load impedance I/ ＜ 300 Ohm, U/ ＞ 1k Ohm
No-load current ≤30mA
Product Description
Main Features:
  • Full Metal M30 installation threaded sleeve
  • Used in harsh environments
Basic Features:
  • 1 pc npn switching output
  • Support digital RS485, modbus-rut standard protocol communication
  • Implementing detection distance learning function through gray lines
  • Temperature compensation
  • Standard operating voltage DC 10-30V
Technical Data
Model U30-D4000N(P)1T-R00A
Detection range 200-4000mm
Blind zone 0-200mm
Resolution 0.17-1.5mm
Repeatability ±0.15%F.S.
Accuracy ±1%(built-in temperature drift compensation)
Response time 162ms
Switching hysteresis ±4mm
Switching frequency 5Hz
Initialization time < 500ms
Supply voltage 10-30V DC, reverse-polarity protection
Red LED no object detected: Lights up, teaching-in when no object detected: Flashes
Green LED object detected: Lights up, teaching-in when object detected: Flashes
Overcurrent protection 200mA, Red LED and Green LED flashing at the same time
Load impedance I/ ＜ 300 Ohm, U/ ＞ 1k Ohm
No-load current ≤30mA
Input type Teach-in and synchronization
Material Copper nickel-plated, plastic fittings, glass epoxy resin
Enclosure rating IP67
Connection type 5pin, M12 connector
Ambient temperature -25℃ ~ +70℃ (248~343K)
Storage temperature -40℃ ~ +85℃ (233~358K)
Weight 145g
Output type N1: 1 npn switching output, NO/NC
Product Images
M12 Industrial Ultrasonic Sensors NPN 5 Pin Detection Range 200 - 4000mm 0 M12 Industrial Ultrasonic Sensors NPN 5 Pin Detection Range 200 - 4000mm 1 M12 Industrial Ultrasonic Sensors NPN 5 Pin Detection Range 200 - 4000mm 2 M12 Industrial Ultrasonic Sensors NPN 5 Pin Detection Range 200 - 4000mm 3 M12 Industrial Ultrasonic Sensors NPN 5 Pin Detection Range 200 - 4000mm 4
Tags:

Industrial Ultrasonic Sensor,

Ultrasonic Detection Sensor,

Ultrasonic Sensor NPN
